Description
BTM186B low-pressure burst testing machine is used in conventional blasting test of low-pressure specimens such as water pipe, pure rubber hose, turbocharged pipe, evaporator, condenser, radiator, filter and so on. The test pressure, pressure rate and other parameters can be set in the test program, after setting the machine can be completed automatically. Test the maximum pressure of the specimen under normal temperature, and judge whether the quality of the specimen meets the requirements according to relevant standards. Involving quality inspection institutions, auto parts, aerospace, construction machinery, shipbuilding industry, colleges and universities, research institutes and many other fields.
Features
1. The diversity of test waveforms can realize the curve of direct booster blasting, one-stage booster pressure-retaining blasting and two-stage booster pressure-retaining blasting;
2. Pressure test process can be set in advance before the operation of the equipment, including pressure boost rate, pressure holding, pressure holding time and other related parameters;
3. The structure design of hydraulic control cabinet and test box adopts a unified style, and the overall appearance of the equipment is harmonious and beautiful;
4, the internal structure is reasonable, the layout is beautiful, the use of non-welding pipeline connection, eliminate running and leaking, and convenient maintenance;
5. Written by Siemens PLC; High quality hydraulic components and control components ensure the safety and stability of the equipment for long time operation.
Name | Description |
Model | BTM186B |
Specimen | Cooling water pipe, nylon pipe, rubber pipe, turbocharging pipe, etc |
Pressure | 0.05 ~ 1.8MPa |
Pressure boost | Air-on-fluid |
Pressure accuracy | ±0.5%FS |
Pressure control accuracy | ±2%FS |
Rate of pressure rise | 0.1~10MPa/min |
Test medium | Water |
Medium temperature | RT |
Chamber temperature | RT |
Specimen No. | 1 |
