The ETM type B Series addresses the needs of standardized and routine testing, providing the user high quality at the most affordable price. The dual column testing systems are suited for tension and/or compression applications with load range requirements from 10N to 10kN. They are typically used for quality control and production testing.

Typical specimens: Small components, reinforced plastics, metals, wire, composites, elastomers, wood products, textiles, biomaterials, paper products, adhesives, foam, consumer products

New Features

·          Non-clutched drives, rated for full speed at maximum force

·          Compact design saves lab space

·          Wider test width

 High Quality at affordable price

·          Pre-loaded ball screws and heavy duty bearings assure long life with zero backlash as well as linear low force and through zero performance. The result is accurate and repeatable measurements that truly represent the specimen characteristics rather than load frame deficiencies

·          Fully-protected lead screw covers provide longer life and greater operator protection

·          Easy-to-clean aluminum column covers with chamfered corners to facilitate access to the test area. T-slots are built in for simple, convenient attachment and positioning of testing accessories

·          High-speed, low vibration, world-class, maintenance-free, imported AC servo motor and servo controller

·          Photoelectrical encoder built in servo motor system is for position measurement of crosshead

·          Built-in bidirectional load cell is assembled in the middle crosshead to prevent any collisions and simple to perform compression or tension tests

·          Dual action over-travel limits on all frames provide the highest level of safety and meet all international standards

·          Remote control keypad facilitates test operation

·          Full one-year warranty on parts and labor

·          Free software upgrading

 Full complement of test accessories

Extensive range of accessories to meet test requirements in almost any application or industry: plastics, metals, biomedical, composites, elastomers, components, automotive, aerospace, textiles, and more.

·        Tension grip

·        Peel/tear fixture

·        Compression fixture

·        Flexure fixture

·        Film COF test fixture

·        S type load cells: 10N~5kN

·        Long travel extensometer

·        Clip-on extensometer

·        T-slot table

·        Others

 Machine dimension:

 Specifications:

Shipping information:

Typical specimens: Small components, reinforced plastics, metals, wire, composites, elastomers, wood products, textiles, biomaterials, paper products, adhesives, foam, consumer products
