300kN rebend testing machine

Description Applications Contact us

Description

This horizontal type of testing machine is to perform rebend test of ribbed bars used for construction. It is one-direction loading, easy to bend 50mm diameter rebar to 90°and rebend to 20°. Span is adjusted by motorized ball screw. The support roller is self-lock. Mandrel is easy to change.

Standards

ISO6935-2, GB 1499.2

Specifications

Model	HBT305H
Capacity (kN)	300
Piston travel (mm)	250
Piston moving speed without loading (mm/s)	0.5-4
Rebar diameter	6-50
Support roller (mm)	58.5
Distance between rollers (mm)	80~478
Mandrel diameter (mm)	30~450
Bending angle	Bend 90°, rebend 20°
Dimension (LxWxH), (mm)	1630x980x1410
Hydraulic oil volume (L)	68L
Power consumption (kW)	5.5KW
Weight (kg)	1000
