Compatible with model

ETM-C

Temperature range

-70~+350℃

-40~+350℃

Wind circulation method

centrifugal blower

Temperature fluctuation

≤±1℃

Temperature accuracy

≤±2℃ (≤200℃), ≤±3.5℃ (＞200℃)

Temperature uniformity

≤2℃ (≤200℃), ≤3.5℃ (＞200℃)

Temperature reading accuracy

≤±0.1℃

Heating time

≥3℃/min

Cooling time

≥2℃/min

Cooling method

Compressor

Inside dimension (DxWxH)

240mm×200mm×600mm

Outside dimension (LxWxH)

1820mm×650mm×930mm

Weight

320kg

310kg

Heating power consumption

4.7kW

4.3kW

Power supply

3-phase, AC380V±10%, 50Hz

Pull rod hole diameter

φ48mm

φ48mm

Compatible with model

ETM-D

Temperature range, ℃

-70~+350

-40~+350

Wind circulation method

centrifugal blower

Temperature fluctuation, ℃

≤±1

Temperature accuracy

≤±2℃ (≤200℃), ≤±3.5℃ (＞200℃)

Temperature uniformity

≤2℃ (≤200℃), ≤3.5℃ (＞200℃)

Temperature reading accuracy, ℃

≤±0.1℃

Heating time, ℃/min

≥3

Cooling time, ℃/min

≥2

Cooling method

Compressor

Inside dimension (DxWxH), mm

320×300×600

Outside dimension (LxWxH), mm

1900×710×930

Weight, kg

350

330

Heating power consumption, kW

5.3

4.9

Power supply

3-phase, AC380V±10%, 50Hz

Pull rod hole diameter, mm

φ48

φ48
